◆ Build-in MP3 player, FM tuner and bluetooth
◆ 2 MIC input, MIC1 with muting function, 1 AUX input; 1 AUX out for link
◆ Individual/Master volume control for all inputs, BASS and TREBLE tone control
◆ Output: 70V, 100V, 4~16Ω
◆ With bluetooth player
◆ LED indicator
◆ Short circuit, overload, high temperature protection
Model |
PM-1060 |
PM-1120 |
Rated output power |
60W |
120W |
Output |
Low impedance |
4-16Ω |
70V |
51Ω |
41Ω |
100V |
167Ω |
83Ω |
AUX output level |
0.775V (0dBV) |
Input level |
MIC 1,2 |
600Ω, 5-10mV (unbalanced) |
AUX |
10KΩ, 150-470mV (unbalanced) |
Frequencey response |
60Hz-15KHz (±3dB) |
T.H.D. |
<0.5% at 1KHz, 1/3 rated output power |
S/N ratio |
MIC 1,2 |
≥72dB |
AUX |
≥85dB |
Tone |
Bass |
±10dB at 100Hz |
Treble |
±10dB at 12KHz |
Muting function |
MIC1 overrides other input signals at 0~30dB |
Controls |
Volume, tone/treble, mute, power |
Protection |
AC fuse, overload, short circuit, high temperature |
FUSE×4A |
FUSE×8A |
Cooling fan |
DC 12V FAN |
LED indicator |
AC: POWER, level: 2、4、6、8、10 |
Power supply |
AC220~240V, 50-60Hz |
Power consumption |
84W |
168W |
Power cord |
(3×0.5 mm2)×1.5M (standard) |
Product dimension |
72(H)×305(W)×275(D) mm |
Packing dimension |
130(H)×345(W)×345(D) mm |
Net weight |
5.00Kg |
5.50Kg |
Packing weight |
5.70kg |
6.20kg |
