◆ Multiple channels in 19” standard rack cabinet
◆ 70V/100V power output optional
◆ Full digital with 2*125W / 2*250W / 2*500W high efficiency
◆ With priority input function and 100V input
◆ 1 U slim design, space and cost saving
◆ With standby function for power saving
-
Specification
Model |
DA-2125 |
DA-2250 |
DA-2500 |
Channel |
2 |
2 |
2 |
Rated power per channel |
125W |
250W |
500W |
Rated output power |
70V/100V |
70V/100V |
70V/100V |
Input sensitivity |
775mVRMS(0dBV/balanced input);
100VRMS (100V unbalanced input |
S/N ratio |
>80dB |
Input impedance |
60K Ohms (balanced), 20K Ohms (priority), 100K Ohms (100V unbalanced) |
Frequency response |
80Hz-15kHz (±3dB) |
T.H.D. |
<0.3 % (1kHz) |
Power consumption |
300W |
600W |
1200W |
Power requirement |
AC180-260V/50-60Hz DC24V(rated power -3dB) |
Net weight (Kg) |
6.7 |
6.9 |
7.3 |
Gross weight (Kg) |
8 |
8.2 |
8.6 |
